Downstream pipeline cannot be created: insufficient permission to set variable

[Oscar]

Problem Overview

When one pipeline (upstream) attempts to trigger another (downstream) and passes along variables, Azure DevOps performs a permission check. If the pipeline’s identity (usually a service connection or project build service) lacks permission to set pipeline variables in the downstream pipeline, the trigger fails with the error mentioned.

---

Steps to Resolve the Error

1. Understand the Context

Determine:

• Which pipeline is upstream?
• Which one is downstream?
• Are you using resources: pipelines or trigger: none with a manual runPipeline call via REST API?
• What variables are being passed?

---

2. Check Pipeline Permissions

a. Build Service Permissions

Azure DevOps uses project-level build service accounts (like Project Collection Build Service (org_name) or Project Build Service (project_name)).

Ensure the build service identity of the upstream project has the following permissions:

• Queue builds
• Read & execute pipelines
• Set pipeline variables (if applicable)

To Grant Permissions:

1. Go to Project Settings > Pipelines > Service connections or Project Settings > Repositories > Security.
2. Add Project Build Service (project-name) to the downstream pipeline repository’s security.
3. Grant it:

• Contribute
• Read & execute
• Queue builds
• Set build variables (if available)

4. Save.

---

3. Avoid Restricted Variables

Azure DevOps restricts some predefined variables like:

• System.*
• Build.*
• Release.*

You cannot set or override these from an upstream pipeline unless you’re an administrator.

If your upstream pipeline is trying to pass a restricted variable, you’ll hit the “insufficient permission” error.

Solution:

Only pass custom variables or use template parameters when appropriate.

---

4. Use Runtime Parameters (if needed)

Instead of setting variables from upstream, consider using runtime parameters in the downstream pipeline:

parameters:
  - name: buildVersion
    type: string

Then call the pipeline with:

resources:
  pipelines:
    - pipeline: upstream
      source: UpstreamPipeline
      trigger:
        branches:
          include:
            - main

pr:
  branches:
    include:
      - main

jobs:
- job: RunDownstream
  steps:
    - script: echo "Version: ${{ parameters.buildVersion }}"

---

5. Use REST API With Proper Authentication

If you’re triggering the downstream pipeline manually using a REST API (e.g., POST https://dev.azure.com/{org}/{project}/_apis/pipelines/{pipelineId}/runs), you must:

• Authenticate using a personal access token (PAT) or service principal with correct permissions.
• Pass parameters in the correct format.
• Ensure the token has permission to queue builds and access variable groups, if used.

---

Example Fix: YAML Pipeline Permissions

Let’s say you’re trying to trigger a downstream pipeline and pass a variable:

# Upstream pipeline
trigger:
- main

jobs:
- job: triggerDownstream
  steps:
  - task: AzurePipeline@1
    inputs:
      targetProject: 'MyProject'
      targetPipeline: 'downstream-pipeline'
      parameters: |
        buildVersion=$(Build.BuildId)

You must ensure:

• The build service (Project Build Service (MyProject)) has Queue builds permission on the downstream pipeline.
• You’re not passing restricted variables like Build.BuildNumber.

---

Summary

Step	Action
1	Identify which variable is causing the issue.
2	Avoid using restricted variables (System., Build.).
3	Use runtime parameters or environment variables.
4	Assign permissions to the upstream pipeline’s build service account.
5	If using REST API, ensure correct PAT or identity and headers.

---

If you want, I can help you debug your specific pipeline YAML and permissions setup — just paste the snippet you’re working with.
